    21.5" LVDS Interface 0.175mm OCA Capacitive Touch Panel

    Ask Lasest Price
    Brand Name : Touch-China
    Model Number : ZCC-6826
    Certification : 3C, CE, FCC, RoHS
    Payment Terms : T/T
    Delivery Time : 15 working days
    • Product Details
    • Company Profile

    21.5" LVDS Interface 0.175mm OCA Capacitive Touch Panel




    21.5inch LCD Touch Screen Module


    LCD Panel parameters

    Screen size21.5inch
    Aspect ratio16:9
    Resolution1920*1080
    Visible area

    (H)476.064mm×(V)267.786mm

    Viewing angle89/89/89/89 (Typ.)(CR≥10)

    Contrast Ratio

    3000:1
    Response time13/5 (Typ.)(Tr/Td); 20 (Typ.)(G to G) ms
    Colors8Bit 16.7M , 72% NTSC
    Scanning frequency60Hz
    Interface

    LVDS(See 1.2 for details)

    Operation voltage5V

    Back light parameters

    Back light sourceWLED

    Luminance

    350cd/㎡
    Operation lifeMin. 30K hours
    Operation voltage58~65V
    Operation current240mA
    Power consumption

    Max. 10.6W(for reference)


    Touch screen parameters

    Touch screen type

    10 point G+G capacitive touch panel

    Touch Module

    Finger or capacitor pen

    Response speed10ms
    Reported rate100Hz
    Resolution≥4096×4096
    Touch lifespanDurable single-point≥30 million times
    InterfaceUSB
    Working voltageTypical value+5VDC
    Thickness2.45mm±0.2(Cover1.1mm+SCA0.25mm+Senser1.1mm)
    Surface hardness≥7H
    Transmittance≥85%

    Shipments
    TNT, DHL, UPS, FedEx etc.
