12.5 inch USB COB 10 points white printing capacitive industrial
touch panel screen pc
It’s a kind of projected touch panel with USB interface. It can
support win7, win8 OS and can realize 10 finger point touch.
Product Specification:
| Size: | 12.5inch |
| Total Thickness: | 1.85±0.2mm |
| Outline of Cover Lens: | 301.48*182.52±0.1mm |
| Outline of ITO Sensor: | 297.48*178.52±0.3mm |
| Viewing Area: | 277.48*156.52±0.2mm |
| Active Area: | 278.48*157.52±0.3mm |
TP Structure: | G+G |
| Controller: | ILITEK, WEIDA, EETI, Silicon Works etc.(Optional) |
| Cover glass thickness: | 1.1mm,1.8mm,2mm,3mm,4mm,5mm,6mm (Optional) |
| Cover glass treatments: | AG, AR, AF, AE (Optional) |
| CTP interface: | USB |
| Operating system: | Win7, Win8, Win10, WCE, Android, Linux, XP |
| Working temperature and humidity: | -20°C~70°C,20~85% RH, non-condensing |
| Storage environment and humidity : | -30°C~80°C, 20~85% RH, non-condensing |
| Transparency | ≥85% |
| Response time: | <10ms |
| ESD Air discharge: | 8KV |
| ESD Contact discharge: | 4KV |
| Pen hitting life: | ≥10,000,000/point |
| Pen sliding Durability: | ≥500,000 times |
| Finger Touch life: | ≥35,000,000 times |
| Certifications: | CE, FCC, Rohs |
| Aspect ratio: | 16:9 |
| Report rate: | 100HZ |
| Input method: | Finger or capacitive pen |
| Warranty: | 1 Year |
What we believe in:
1.We guarantee customer satisfaction. Our staff is fully trained
and knowledgeable about every product we offer, ready to assist you
with whatever information is needed.
2. We have good resources of the raw materials, which make us
capable of delivering the goods at stable cost and on time.
3. Our entire team works hard to always provide our customers with
the best products and service on the market.
4. Feel free to contact us at any time with any questions, or to
learn more about our high quality product for your unique company.
Touch-China Service
OEM/ODM are workable
All of products can be customized according to customers' drawings,
and with customer's brand.
If you no drawing or sample, please let me know some information,
our engineer can help you to develop new items and make technical
drawing.
Assembly Services
We can provide assembly services. We mainly manufacture touch
screen, also can make optical bonding / tape bonding between touch
screena and LCD display from 3.5~86inch.
FAQ:
Q. Does your products have CE & Rohs certificates?
A: Yes, of course.
Q. What’s the shipping method?
A: By sea / air / express, which methods to be used on the basis of
customer’s requirements.
Q. What’s the payment methods?
A: T/T, 30% deposit before production, the balance before shipment.
Q: How many people are there in your factory?
A: There are about 500 people in our factory.
Q: What’s your lead time?
A: The lead time for both samples and mass production is 15 days.
Q: Are you a trading company or manufacturer?
A: We are a manufacturer. We can provide both OEM and ODM service.
Q: What kind of products can you provide?
A: We can provide capacitive touch panel from 3.5” to 86” and
optical bonding products.
Q: How to deal with the defective touch panel after they are shipped?
A: First, we will make clear what the issue is. Usually the issue
can be solved by either remote testing or sending back
representative defective touch panels.
PCAP touch Technical Drawings:
