    15 Inch Anti Explosion Touch Screen Control Panel With IIC USB Port

    Ask Lasest Price
    Brand Name : OEM/ODM
    Model Number : ZCC-8365
    Certification : FCC/CE/ROHS/CCC
    Price : Negotiation
    Payment Terms : L/C, T/T, Western Union, MoneyGram
    Supply Ability : 5K/per month
    Delivery Time : Samples 3-5working days
    • Product Details
    • Company Profile

    15 Inch Anti Explosion Touch Screen Control Panel With IIC USB Port

    15 Inch Anti Explosion Touch Screen Control Panel With IIC USB Port


    Capacitive Touch Screen:

    Capacitive touch screen is very different from traditional resistive touch screen. When the resistive touch screen works, you can only judge a touch point. And if there are two or more touch points, you can not make the right judgments. So the resistive touch screen applies only to judge a few simple actions such as click, drag and drop. The capacitive multi-touch screen can decompose the user's touch into collecting multi-point signal and determining the significance of the signals, and complete the judgments of complex action. Moreover, you can feel it when you lightly touch the projected capacitive touch sensor panel. Better durability, more than 90% light transmission rate, high transparency than the traditional resistive touch screen are the advantages of our products.


    Features:

    1. Projected Capacitive touch screen

    2. Customization

    3. 3.5 inch to 85 inch

    4. Multi touch point

    5. OS support: Windows 7/ 8/ 10, Android, Linux, XP, WCE

    6. USB/ I²C port

    7. Low MOQ


    Specification

    ItemSpecification
    1Item modelZCC-8365
    2Detection methodProjected Capacitive
    3Size15"
    4Aspect ratio4:3/16:9
    5ResolutionAccording to the size
    6Input methodFinger/capacitive touch pen
    7Touch action force30~60g
    8Operating Voltage3.3V adjustable
    9Operating current2.5~10mA Depends on IC
    10Operating temperature-10°C~60°C
    11Storage temperature-20°C~70°C ,<85%RH;
    12Humidity10%~90%RH at 40°C, non-condensing
    13Relative humidity10%~90%RH at 40°C, non-condensing
    14Response time<8/10ms
    15Transparency≥83% depends on the quantity of layers
    16Surface hardness≥6H
    17MaterialG+G
    18Thickness

    5mm adjustable


    19Light transmission83-90%
    20DurabilityScratch-free; More than 50,000,000 touches in one location without failure
    21Drivers availableWindows 10,Windows 7/8/XP,,Linux,Mac,Android
    22CertificatesCE, FCC, RoHS, CCC
    23Working environmentUnder sunlight,indoor and outdoor
    24Finger Touch life≥50,000,000 times
    25Warranty1 year


    Product detailed drawing for reference:



    Some Product case for reference


    Package with export standard



    Reliability Test:

    Touch Panel Reliability Test Condition

    1. Set the initial temperature to be 25℃

    2. Ramp to 80℃at 90% RH, 2H

    3 .Soak at 80℃at 90% RH, 2H

    4. Ramp from 60℃at 90% RH to -20℃, 4H

    5. Soak to -20℃, 2H

    6. Ramp from -20℃to 25℃, 2H


    ConditionTemp.HumidityTime
    Initial condition25℃//
    Ramp to 80℃60℃90%2H
    Soak60℃90%2H
    Ramp to -20℃-20℃/4H
    Soak-20℃/2H
    Ramp to initial temperature25℃/2H
    12H for each cycle(from step 1 to 6), total 28 cycles.Duration of one circle12H
