    IPC Waterproof IP65 10.4 inch Rugged P-Cap Touch monitor 50K hours working life

    Ask Lasest Price
    Brand Name : Touch-China
    Model Number : ZCK-104CT
    Certification : CE FCC
    Price : Negotiation
    Supply Ability : 2K / month
    Delivery Time : 20-25 days
    • Product Details
    • Company Profile

    IPC Waterproof IP65 10.4 inch Rugged P-Cap Touch monitor 50K hours working life

    IPC Waterproof IP65 10.4 inch Rugged P-Cap Touch monitor 50K hours working life


    Product Specification:

    1. Technical index of Display

    IndexParameter
    PanelScreen Size10.4 inch
    Panel typeLCD
    InterfaceSingle LVDS 6bit
    Backlight typeWLED
    Display area size(H)211.2mm×(V)158.4mm
    Resolution800×600★
    Pixel spacing0.264mm×0.264 ★
    Dynamic contrast800:1 ★
    Brightness300cd/m2 ★
    Display scale4:3
    Visual angleView Angle Free(R/L 140(Typ.),U/D 130(Typ.))
    Response time30ms(Try,on/off)

    • Technology index of touch control device
    IndexParameter
    Function indexTouch panel size10.4inch matches with display device ★4:3
    Touch method10 points capacitive touch
    Thickness of cover glass3mm
    Total thickness4.3±0.3
    Resolution≥4096×4096 ★
    Response speed10ms
    Reported rate100HZ
    Mechanical functionInput methodHand writing or capacitive pen
    Touch timesDurable single-point≥30 million times
    The smallest diameter of touch object8mm
    Explosion-proof

    227g±2g, 100cm, No damage after the

    impact at the central area for once. ★

    Surface DurabilitySurface hardness equals glass, Moh's hardness level≥7
    Optical indexTransmittance≥85%
    working environment-10-60℃,20-85RH
    Electrical characteristicsWorking voltageTypical value+5VDC,Allowance range+4.75v~+5.25v
    Power supplyUSB bus
    InterfaceUSB
    Control driverIC solutionILI2302M

    • Drive display indicators [drive board indicators]
    IndexParameter
    OSD LANGUAGESimplified Chinese, English, Frech, Italian, Russian, Spanish, German, Portuguese
    TO PANELInterfaceDual LVDS (8bit)
    Max Resolution1920×1200
    Panel voltage5V
    Backlight voltage12V
    Luminance regulation1-100 Grade
    VIDEO INPUTPC-RGB640×480@60Hz ,800×600@60Hz
    DVI640×480@60Hz ,800×600@60Hz
    HDMI640×480@60Hz ,800×600@60Hz
    POWERRequirement12V DC
    ManagementStandby Power Consumption < 0.5W(Board Only)
    NO.Description
    1DC INIPC Waterproof IP65 10.4 inch Rugged P-Cap Touch monitor 50K hours working life
    2HDMI IN
    3DVI IN
    4VGA IN
    5Touch screen USB
    ButtonPOWER VOL+ VOL- MENU AUTO
    • Technical index of power supply
    IndexParameter
    DC input parameterVoltage range9V-36V
    Standbay current2.5W
    Maximum current10W
    Power supply certificationSafety standardsUL60950-1,IEC60950,EN60950-1,GB4943
    EMC standardEMC--- EN55022/EN55024/GB9254(CISPR 22) /GB17625.1
    EMI standardFCC Part 15B
    efficiencyFull load output≥90%
    Total powerSupport maximum output power60W

    5. 5. Appearance/size/use of environmental parameters.

    IndexParameter
    Panel materialAluminum alloy
    Back shell materialHigh quality electrolytic plate
    physical dimensionmm
    Mounting hole sizesuggested
    Mounting holesVESA 75/100 mounting hole on back cover
    Waterproof levelfront panel IP65, back cover IP30
    Operating temperature-20 ~ 60°
    Storage temperature-30 – 60°
    Total Weight2.3 kg
    Shell processThe outer shell of the shell is cold rolled plate or aluminum profile, the metal baking paint and the inside of the machine are galvanized anti-rust, shockproof, anti-magnetic, anti-interference, anti-static, complete insulation protection
    Machine appearanceIntegrated industrial design, ergonomic and aesthetic principles, ultra-thin cabinet, rich time breath
    Warranty1 year

    Projected Capacitive Touch panel:


    • Projected capacitive touch panels are built with two parallel layers of ITO but, but unlike the old and cheap resistive touch panels, the ITO layers in a projected capacitive touch panel are sealed between two sheets of glass by an optically clear adhesive.
    • There is no air gap between layers like in a resistive touch panel.
    • The patterns on the two parallel ITO layers form a grid of capacitors.
    • The electric fields of these capacitors are projected through the top layer of glass.
    • When the user places a finger near the top surface of the touch panel, it couples with the electric fields.
    • This coupling changes the capacitance of several of the capacitors in the vicinity of the finger.
    • An algorithm converts these changes in capacitance into a location along the X and Y axes of the panel.

    FAQ:


    Q. Are you a factory or trading company?

    A: We are a factory.

    Q. Does your products have CE&Rohs certificates?

    A: Yes.

    Q. What’s the shipping method?

    A: By sea / air / express, which methods to be used on the basis of customer’s requirements.

    Q. What’s the payment methods?

    A: T/T, 30% deposit before production, the balance before shipment.

    Q. What size of touch screen can you manufacture?

    A: 3.5” to 65”, the bigger size are researching and developing.


    Application:


    -- Kiosk,Karaoke -- All in one --Digital Signage -- Tablet pc

    -- Advertising player -- Education Whiteboard -- Medical device

    -- Industrial PC panel -- Multi-touch table -- POS

    -- Restaurant menu -- ATM

    IPC Waterproof IP65 10.4 inch Rugged P-Cap Touch monitor 50K hours working life
