Anti Interference Multi Touch Capacitive Touchscreen For Car
Navigator
Parameters of the touch panel
| Size: | 7 inch |
| Total Thickness: | 1.95±0.15mm |
| Outline of Cover Lens: | 167.86*91.34±0.1mm |
| Outline of ITO Sensor: | 166.86*90.04±0.3mm |
| Viewing Area: | 151.8*80.48±0.2mm |
| Active Area: | 152.8*81.48±0.3mm |
TP Structure: | G+G |
| Controller: | Goodix 911 |
| Cover glass thickness: | 1.1mm |
| Cover glass treatments: | AG, AR, AF (Optional) |
| CTP interface: | I2C |
| Operating system: | Android, Linux |
| Working temperature and humidity | -20°C~70°C,20~85% RH, non-condensing |
| Storage environment and humidity : | -30°C~80°C, 20~85% RH, non-condensing |
| Transparency | ≥85% |
| Response time: | <10ms |
| ESD Air discharge: | 8KV |
| ESD Contact discharge: | 4KV |
| Pen hitting life: | ≥10,000,000/point |
| Pen sliding Durability: | ≥500,000 times |
| Finger Touch life: | ≥35,000,000 times |
| Certifications: | CE, RoHS, REACH |
| Aspect ratio: | 16:9 |
| Report rate: | 100HZ |
| Input method: | Finger or capacitive pen |
| Ball drop test standard | 227g, 100cm for 3 times |
| Warranty: | 1 Year |
Reliability test conditions
High temperature: 70℃, 120H / Low temperature: -20℃, 120H
Thermal shock: -20℃(0.5 hour)- 70℃(0.5 hour)by 50 cycles
Humidity resistance: 85%RH for 120 hours
Heat resistance: 80℃ for 120 hours
Cold resistance: -30℃ for 120 hours
Project proceeded steps
1. Receipt of customer’s RFQ ( detailed requirements of the touch
panel, qty. Needed etc.)
2. Evaluate the drawing and offer the redesigned drawing and
quotation to the customer.
3. Confirm the drawing and quotation.
4. Go ahead with sample manufacturing
5. Samples’ testing and confirmation of samples
6. Mass production
7. Shipment, follow up with the feedback of mass production.
