    Glove touch 10.1 Inch Projected Capacitive Touch Panel For industrial Control

    Ask Lasest Price
    Brand Name : Touch China
    Model Number : ZCC-3972V1
    Certification : CE,ROHS,FCC
    Price : Negotiable
    Payment Terms : T/T
    Supply Ability : 20K pcs per month
    Delivery Time : 10-15 days
    • Product Details
    • Company Profile

    Glove touch 10.1 Inch Projected Capacitive Touch Panel For industrial Control

    Glove touch 10.1 Inch Projected Capacitive Touch Panel For industrial Monitor




    4:3 & 16:10 & 16:9. Glove touch, waterproof, anti-glare, anti-finger, anti-reflective. IIC and USB interface.

    Basic specification:

    Size10.1 inch
    Total thickness3.3±0.2mm
    Outline of Cover Lens243.56*155.54+0.1mm
    Outline of ITO Sensor227.11*147.7±0.2mm
    Viewing Area217.06*135.4±0.2mm
    Active Area218.8*137.4±0.3mm
    InterfaceUSB
    Input voltage5V
    Response time<10ms
    Report rate100 HZ
    Input methodHand writing or capacitive pen
    Transmittance﹥85%
    IC Controller:WEIDA, EETI, Silicon Works (optional)
    Cover glass thickness1.1mm,1.8mm,2mm,3mm,4mm,5mm,6mm (optional)
    Cover glass treatmentsAG, AR, AF, AE (optional)
    Working temperature and humidity-20°C~70°C,20~85% RH, non-condensing
    Storage environment and humidity-30°C~80°C, 20~85% RH, non-condensing
    ESD Air discharge8KV
    ESD Contact discharge4KV
    Package list10.1"Touch panel + USB cable



    Advantages

    • Physically tempered cover glass, support a ball of 500g falling on the center from 1.3m height.
    • Enhanced durability and reliability
    • Water proof, anti-explosion.
    • Professional facilities and excellent design
    • Optimized Production Capacity
    • Optimized Production Capacity

    Glove Touch:

    Development process

    • Receive customer's technical files, including PCAP drawing, LCD specification.
    • Recommend standard products or customize products based on customer's requirements.
    • Offer engineering drawing for confirmation and fill in project kick-off form.
    • Make samples according to the confirmed drawing.
    • Debug the samples based on the information on kick-off form, keep the FW.
    • Send the samples to customers for confirmation. Offer all the technical supports with which customer will let the touch panels work well.
    • Pilot production.
    • Mass production



    Delivery time:

    • Samples in stock: 1~3 working days
    • Customized project: 10~15days for samples
    • Mass production: 15~18days




    Technical Drawing:


    Glove touch 10.1 Inch Projected Capacitive Touch Panel For industrial Control
